Portable Surgical LED Light – PAX Light
Designed For Critical, Life-saving Procedures
Designed For Critical, Life-saving Procedures
Contact for Quote.
var aoAdBlockDetected = true;
window.addEventListener(“load”,function(){if(aoAdBlockDetected){var t=document.createElement(“div”),o=document.createElement(“div”),e=document.createElement(“div”),n=document.createElement(“div”),d=document.createElement(“button”),i=”
Some of the forms and images on this page may not work correctly with this enabled. Please disable your ad blocker for this page.
Instructions
1. Find the ad blocker icon installed on your browser.
This icon is usually located on the upper right side of your screen. You may have more than one ad blocker installed.
2. Click the icon and disable the ad blocker for this website.
3. Refresh this website page, either by following prompts or clicking your browser’s “refresh” or “reload” button.
“;t.style.cssText=”position:fixed;top:0;left:0;width:100vw;height:100vh;z-index:1000;background:red;background: rgba(0,0,0,0.3);”,o.style.cssText=”position: fixed; top: 50%; left: 50%; width: 600px; max-width: 80vw; transform: translate(-50%, -50%) !important; background: #ffffff; border-width: 1px; border-radius: 4px; border-color: #444444; border-style: solid; max-height: 80vh; overflow: auto; padding: 24px 56px 0 56px;”,o.innerHTML=i,n.style.cssText=”margin-top: 36px; margin-bottom: 24px; text-align: center;”,o.appendChild(n),d.innerHTML=”Refresh Page”,d.style.cssText=”cursor: pointer; padding: 12px 24px; background: #FFFFFF; border-width: 1px; color: #444444; border-color: #444444; border-radius: 4px;”,n.appendChild(d),d.addEventListener(“click”,function(){window.location.reload()}),e.style.cssText=”position: absolute; right: 25px; top: 25px; cursor: pointer; font-size: 14px; line-height: 14px; color: #444444″,e.innerHTML=”✕”,e.addEventListener(“click”,function(){o.parentNode.removeChild(o),t.parentNode.removeChild(t)}),document.body.appendChild(t),t.appendChild(o),o.appendChild(e)}});
!function(o,t,e,a){o._aoForms=o._aoForms||[],o._aoForms.push(a);var n=function(){var o=t.createElement(e);o.src=(“https:”==t.location.protocol?”https://”:”http://”)+”marketing.spartacogroup.com/acton/content/form_embed.js”,o.async=!0;for(var a=t.getElementsByTagName(e)[0],n=a.parentNode,c=document.getElementsByTagName(“script”),r=!1,s=0;s
WARNING: Cancer and Reproductive Harm – California Proposition 65 Warning.
Designed For Critical, Life-saving Procedures
|
Light Output |
Minimum 50,000 lux (4,590 fc) @ 1 m |
|
Input Voltage |
100-240 VAC, 50/60 Hz |
|
Power Consumption |
152.5 W |
|
Current Draw |
1.4 A @ 110 VAC |
|
Color Temperature |
4000K |
|
Color Rendering Index (CRI) |
95 |
|
Depth of Illumination |
860mm |
|
Operating Temperature |
-17° C to 49° C (0° F to 120° F) |
|
Storage Temperature |
-40° C to 70° C (-40° F to 158° F) |
|
Relative Humidity |
5% to 90% non-condensing |
|
Altitude |
0 – 10,000 feet |
|
Light Field Diameter (d10) |
420mm |
|
Focal Length |
36″ |
|
Dimensions/Weight |
Case: 46″ x 20″ x 9″ Pole: 35″ Total Weight: 43 lb. |
|
Adjustment Range |
Height: 53″ (1.3m) Radial: 30″ (0.75m) Circumference: 360° Head Pitch: 30° – 60° |
